Replication settings

You can configure settings for the data replication task.

• Open the replication task and click Settings in the toolbar.

The Settings: <Task-Name> dialog opens. The available settings are described below.

General

In this tab, you can change the replication mode, the staging settings (when available), and the mode for applying changes to the target.

Replication mode

The following replication modes are available:

• Full load: Loads the data from the selected source tables to the target platform and creates the target tables if necessary. The full load occurs automatically when the task is started, but can also be performed manually should the need arise. Manual full load would be required, for example, if you need to replicate updates to Views (which are not captured during CDC) or if you are replicating from a data source that does not support CDC.

• Apply changes: Keeps the target tables up-to-date with any changes made to the source tables.

• Store changes: Stores the changes to the source tables in Change Tables (one per source table).

  For more information, see Store changes.

When working with Data Movement gateway, changes are captured from the source in near real-time. When working without Data Movement gateway (for example, with a Qlik Talend Cloud Starter subscription or when selecting None), changes are captured according to the scheduler settings. For more information, see Replication settings.

If you select Store changes or Apply changes and your source data contains tables that do not support CDC, or views, two data pipelines will be created. One pipeline for tables that support CDC, and another pipeline for all other tables and views that support Full load only.

Loading method

When replicating to Snowflake, you can choose one of the following loading methods:

• Bulk loading (the default)

  If you select Bulk Loading, you will be able to tune the loading parameters in the Data uploading tab.

• Snowpipe Streaming

  Information note

  Snowpipe Streaming will only be available for selection if the following conditions are met:

  • The Store changes replication mode is enabled, without Apply changes.
  • The Authentication Mechanism in the Snowflake connector is set to Key Pair.
  • If you are using Data Movement gateway, version 2024.11.45 or later is required.

  If you select Snowpipe Streaming, make sure you are familiar with the limitations and considerations when using this method. Additionally, if you select Snowpipe Streaming and then enable the Apply changes replication mode or disable Store changes, the loading method will be automatically switched back to Bulk loading.

The main reasons to choose Snowpipe Streaming over Bulk loading are:

• Less costly: As Snowpipe Streaming does not use the Snowflake warehouse, operating costs should be significantly cheaper, although this will depend on your specific use case.

• Reduced latency: As the data is streamed directly to the target tables (as opposed to via staging), replication from the data source to the target should be faster.

Connecting to a staging area

When replicating to the data warehouses listed below, you need to set a staging area. Data is processed and prepared in the staging area before being transferred to the warehouse.

• Amazon Redshift
• Microsoft Fabric
• Databricks

Either select an existing staging area or click Create new to define a new staging area and follow the instructions in Connecting to cloud storage.

To edit the connection settings, click Edit. To test the connection (recommended), click Test connection.

For information on which staging areas are supported with which data warehouses, see the Supported as a staging area column inTarget platform use cases and supported versions.

Apply changes mode

Changes are applied to the target tables using one of the following methods:

• Batch optimized: This is the default. When this option is selected, changes are applied in batches. A preprocessing action occurs to group the transactions into batches in the most efficient way.
• Transactional: Select this option to apply each transaction individually, in the order it is committed. In this case, strict referential integrity is ensured for all tables.

Data uploading

This tab will only be shown when replicating to a data warehouse or Kafka target. Additionally, the settings in this tab will differ according to the selected target.

Relevant for all data warehouse targets

Maximum file size

The maximum size a file can reach before it is closed. Smaller files might be uploaded faster (depending on the network) and improve performance when used in conjunction with the parallel execution option. However, it is generally considered bad practice to clutter the database with small files.

Relevant for Snowflake target only

In the General tab, you can select whether to load the data to Snowflake using Bulk Loading or Snowpipe Streaming. When Snowpipe Streaming is selected, the Data uploading tab will not be shown. When Bulk Loading is selected, the following settings will be available:

• Maximum file size (MB): Relevant for the initial Full Load and CDC. The maximum size a file can reach before it is loaded to the target. If you encounter performance issues, try adjusting this parameter.

• Number of file to load in a batch: Relevant for the initial Full Load only. The number of files to load in a single batch. If you encounter performance issues, try adjusting this parameter.

For a description of the Bulk Loading and Snowpipe Streaming loading methods, see General.

Relevant for Kafka target only

Message properties

Compression

Optionally select one of the available compression methods (Snappy or Gzip). The default is None.

Data message publishing

Choose one of the following Publish the data to options:

• Specific topic: Publishes the data to a single topic. Either type a topic name or use the browse button to select the desired topic.

• Specific topic for each table: Publishes the data to multiple topics corresponding to the source table names.

  The target topic name consists of the source schema name and the source table name, separated by a period (for example, dbo.Employees). The format of the target topic name is important as you will need to prepare these topics in advance.

For information on overriding this setting at dataset level, see Overriding task settings for individual datasets when publishing to Kafka

Message key

Select one the available options.

• Primary key columns: For each message, the message key will contain the value of the primary key column.

  When By message key is selected as the Partition strategy, messages consisting of the same primary key value will be written to the same partition.

• Schema and table name: For each message, the message key will contain a combination of schema and table name (for example, dbo+Employees).

  When By message key is selected as the Partition strategy, messages consisting of the same schema and table name will be written to the same partition.

• None: Creates messages without a message key.

For information on overriding this setting at dataset level, see Overriding task settings for individual datasets when publishing to Kafka

Partition strategy

Select either Random or By message key. If you select Random, each message will be written to a randomly selected partition. If you select By message key, messages will be written to partitions based on the selected By message key (described below).

Metadata message publishing

Subject name strategy

Select one of the available subject name strategies.

• Schema and Table name (default)
• Topic name
• Record name
• Topic and record name

For more information on Confluent's subject name strategies, see Subject name strategy

Subject compatibility mode

Select one of the following compatibility modes from the Subject compatibility mode drop-down list:

• Use Schema Registry defaults: Retrieves the Compatibility Level from the Schema Registry server configuration.

• Backward - Latest schema only: New schemas can read corresponding data and data produced by the latest registered schema only.

• Backward Transitive - All previous schemas: New schemas can read data produced by all previously registered schemas.

• Forward - Latest schema only: Latest registered schema can read data produced by the new schema.

• Forward Transitive - All previous schemas: All previously registered schemas can read data produced by the new schema.

• Full - Latest schema only: New schema is backward and forward compatible with latest registered schema.

• Full Transitive - All previous schemas: New schema is backward and forward compatible with all previously registered schemas.

• None

Message attributes

You can specify custom message attributes that will override the default message attributes. This is useful if the consumer application needs to process the message in a particular format.

Custom message attributes can be defined at both task and table level. When the attributes are defined at both task and table level, the message attributes defined for the table will take precedence over those defined for the task.

For information on overriding the message attributes at dataset level, see Overriding task settings for individual datasets when publishing to Kafka

General rules and usage guidelines

When defining a custom message, it is import to consider the rules and usage guidelines listed below.

Section names

The following naming rules apply:

• Section names must start with the characters a-z, A-Z, or _ (an underscore) and can then be followed by any of the following characters: a-z, A-Z, 0-9, _
• With the exception of the Record name and Key name sections (that do not end with a slash), removing the slash from section names will flatten the hierarchy of the associated section (see Slashes below).
• All section names except Record name and Key name can be deleted (see Deletion below)

• The Data name and Include record Before-data section names cannot both be deleted

• The Data name and Include record Before-data section names cannot be the same

Slashes

Some of the section names in the UI end with a slash (e.g. beforeData/). The purpose of the slash is to maintain a hierarchy of the different sections within the message. If the slash is removed, the following will occur:

• The hierarchical structure of that section will be flattened, resulting in the section name being removed from the message
• The section name will be prefixed to the actual metadata, either directly or using a separator character (e.g. an underscore) that you appended to the name

Example of a data message when headers/ is specified with a slash:

		"message":{
		        "data":{
			      "COL1": "159",
			      "COL2": "159"
                       },
                       "beforeData": null,
		        "headers": {
			"operation": "INSERT",
			"changeSequence": "2018100811484900000000233",

Example of a data message when headers_ is specified with an underscore instead of a slash:

		"message":{
		        "data":{
			      "COL1": "159",
			      "COL2": "159"
                       },
                       "beforeData": null,
                       "headers_operation": "INSERT",
			"headers_changeSequence": "2018100811484900000000233",

Deletion

Deleting a section name from the message will flatten the hierarchical structure of that section. This will result in all of that section's data appearing immediately below the content of the preceding section.

Example of a data message with the headers section name:

	        "message":{
		        "data":{
			      "COL1": "159",
			      "COL2": "159"
                       },
		        "headers": {
			"operation": "INSERT",
			"changeSequence": "2018100811484900000000233",

Example of a data message without the headers section name:

	        "message":{
		        "data":{
			      "COL1": "159",
			      "COL2": "159"
                       },
                       "beforeData": null,
                       "operation": "INSERT",
			"changeSequence": "2018100811484900000000233",

Variables

You can add variables to names by clicking the button at the end of the row. The following variables are available:

• SERVER_NAME - The host name of the Data Movement gateway server
• TARGET_TABLE_NAME - The name of the table
• TARGET_TABLE_OWNER - The table owner
• TASK_NAME - The name of the data task

Defining custom message attributes

To define a custom message format, toggle on Use custom settings and configure the options as described in the table below.

To revert to the default message attributes, toggle off Use custom settings.

Use a proxy to connect to Confluent Schema Registry

Toggle on if your Data Movement gateway is configured to use a proxy server.

Additional settings

• Message maximum size

  In the Message maximum size field, specify the maximum size of messages that the broker(s) are configured to receive (message.max.bytes). The data task will not send messages larger than the maximum size.

Metadata

Basic

• Target table schema

  The schema on the target to which the source tables will be replicated if you do not want to use the source table schema (or if there is no schema in the source database).

  Information noteWhen replicating to an Oracle target, the default target table schema is "system". Note also that if you leave this field empty (in which case the source schema will be used), you must make sure that the source schema already exists on the target. Otherwise, the task will fail.
  Information noteThe maximum permitted length for the schema name is 128 characters.

JSON column mapping

Map compatible source JSON columns to JSON columns on the target

When this option is selected, JSON columns on the source will automatically be mapped to JSON columns on the target.

The state and visibility of this option is determined by the following factors:

• New tasks: This option will be enabled by default if both the source and the target support the JSON data type.

• Existing tasks: This option will be disabled by default, even if both the source and the target support the JSON data type. This is in order to preserve backward compatibility with downstream processes - such as transformations - that expect the target data to be in STRING format (which is the legacy behavior). You can either leave the option disabled or you can edit the downstream processes to be compatible with JSON format, and then enable this option.

• New and existing tasks: If only the source supports the JSON data type, this option will not be visible. If JSON support is added to the target at a later stage, the option will become visible but remain disabled. This is in order to preserve backward compatibility with downstream processes - such as transformations - that expect the target data to be in STRING format (which is the legacy behavior).

LOB settings

The available LOB settings differ according to the selected replication target. As data warehouse targets do not support unlimited LOB column sizes, this option will not be available when replicating to a data warehouse.

LOB settings for targets that are not data warehouses

• Do not include LOB columns: Select this if you do not want source LOB columns to be replicated.

• Limit LOB column size to (KB): This is the default. Select this option if you only need to replicate small LOBs or if the target platform does not support unlimited LOB size. The maximum permitted value for this field is 102400 KB (100 MB).

  When replicating small LOBs, this option is more efficient than the Do not limit LOB column size option since the LOBs are replicated "inline" as opposed to via "lookup" from the source. During Change Processing, small LOBs are usually replicated via "lookup" from the source.

  The limit applies to the number of LOB bytes that is read from the source endpoint. For BLOB columns, the target BLOB size will be exactly according to the specified limit. For CLOB and NCLOB columns, the target LOB size could differ from the specified limit if the source and target LOB do not have the same character set. In this case, the data task will perform character set conversion, which might result in a discrepancy between the source and target LOB sizes.

  As the value of the Limit LOB size to is in bytes, the size should be calculated according to the following formulas:

  • BLOB: The length of the largest LOB.
  • NCLOB: The length of the longest TEXT in characters multiplied by two (as each character is handled as a double-byte). If the data includes 4-byte characters, multiply it by four.
  • CLOB: The length of the longest TEXT in characters (as each character is handled as a UTF8 character). If the data includes 4-byte characters, multiply it by two.
  Information note

  • Any LOBs larger than the specified size will be truncated.
  • During Change Processing from Oracle source, inline BLOBs are replicated inline.
  • Changes to this setting will only affect existing tables after they are reloaded.

• Do not limit LOB column size: When this option is selected, LOB columns will be replicated, regardless of size.

  Information noteReplicating LOB columns may impact performance. This is especially true in the case of the large LOB columns which require the replication task to perform a lookup from the source table in order to retrieve the source LOB value.

  • Optimize when LOB size is less than: Select this option when you need to replicate both small and large LOBs, and most of the LOBs are small.

    Information note

    This option is supported with the following sources and targets only:

    • Sources: Oracle, Microsoft SQL server, MySQL, PostgreSQL, and IBM DB2 for LUW

    • Targets: Oracle, Microsoft SQL Server, MySQL, PostgreSQL.

    When this option is selected, during Full Load, the small LOBs will be replicated "inline" (which is more efficient), and the large LOBs will be replicated by performing a lookup from the source table. During Change Processing, however, both small and large LOBs will be replicated by performing a lookup from the source table.

    Information note

    When this option is selected, the replication task will check all of the LOB sizes to determine which ones to transfer "inline". LOBs larger than the specified size will be replicated using Full LOB mode.

    Therefore, if you know that most of the LOBs are larger than the specified setting, it is preferable to use the Replicate unlimited LOB columns option instead.

  • Chunk size (KB): Optionally, change the size of the LOB chunks to use when replicating the data to the target. The default chunk size should suffice in most cases, but if you encounter performance issues, adjusting the size may improve performance.

    Information note

    With some databases, data type validation occurs when the data is inserted or updated. In such cases, replication of structured data types (e.g. XML, JSON, GEOGRAPHY, etc.) may fail if the data is bigger than the specified chunk size.

Lob settings for supported data warehouse targets

• Include LOB columns and limit column size to (KB):

  You can choose to include LOB columns in the task, and set the maximum LOB size. LOBs that are larger than the maximum size will be truncated.

Advanced

Control table settings

• Control tables schema: Specify the target schema for the control tables if you do not want them to be created in the source schema (the default), or in the target schema.

  Information noteThe maximum permitted length for the schema name is 128 characters.
• Create target control tables in tablespace: ​ When the replication target is Oracle, specify the tablespace where you want the target control tables to be created. If you do not enter any information in this field, the tables will be created in the default tablespace in the target database.
• Create indexes for target control tables in tablespace: When the replication target is Oracle, specify the tablespace where you want the control table indexes to be created. If you do not enter any information in this field, the indexes will be created in the same tablespace as the control tables.
• Replication history timeslot (minutes): The length of each time slot in the Replication history control table. The default is 5 minutes.

Control table selection

Apply changes

These settings are only available when the Apply changes replication mode is enabled.

Basic

Apply DDL changes to target table

The following options determine whether DDL operations performed on the corresponding source table will also be performed on the target table.

• Drop table: Select to drop the target table when the source table is dropped.

• Truncate table: Select to truncate the target table when the source table is truncated.

  Information noteNot supported when Microsoft Fabric is the target platform.
• Alter table: Select to alter the target table when the source table is altered.

Change processing tuning

• Apply batched changes to multiple tables concurrently: Selecting this option might improve performance when applying changes from multiple source tables.

  Information note

  This option is only supported when:

  • The Apply changes mode is set to Batch optimized. For more information, see Replication settings.
  • The replication targets are not MySQL, PostgreSQL, Oracle, and Google BigQuery.

  • Maximum number of tables: The maximum number of tables to apply batched changes to concurrently. The default is five, the maximum is 50, and the minimum is two.

When the Apply batched changes to multiple tables concurrently option is enabled, the following limitations apply:

• The task error handling policy defaults will be unchanged for Environmental and Table errors, but the defaults for Data errors and Apply Conflicts errors will be as follows:

  • Data errors:
    • Data truncation errors: Log record to the exceptions table
    • Other data errors: Suspend table
  • Apply Conflicts errors:
    • Deletes: Ignore record

    • Inserts: UPDATE the existing target record

      Information noteThis is not relevant for a Snowflake target (as Snowflake does not support Primary Keys).
    • Updates: Ignore record
  • Escalation action:
    • The Escalation action for both Data errors and Apply Conflicts is not supported.
  • The attrep_apply_exception Control Table is not supported.
  • For data errors:
    • The Log record to the exceptions table option is only available for data truncation errors.
    • There is no Ignore option.
  • For Apply Conflicts:
    • The Log record to exceptions table option is not available.
    • The Ignore option is only available for the No record found for applying an UPDATE apply conflict.

See also: Error handling.

• Limit the number of changes applied per change processing statement to: To limit the number of changes applied in a single change processing statement, select this check box and then optionally change the default value. The default value is 10,000.

  Information noteThis option is supported with the following targets only: MySQL, PostgreSQL, Oracle, and Google BigQuery.

Advanced

See Change processing tuning.

Store changes

These settings are only available when the Store changes replication mode is enabled.

Basic

DDL options

Select one of the following options to determine how to handle DDL operations on the source tables:

• Apply to change table: DDL operations to the source tables (such as a column being added) will be applied to the corresponding Change Tables only.
• Ignore: All DDL operations to source tables will be ignored.

Advanced

On update

Select Store before and after image to store both the pre-UPDATE data and the post-UPDATE data. When not selected, only the post-UPDATE data will be stored.

Change table creation

The following section describes the options that are available when storing changes in Change Tables.

• Suffix: Specify a string to use as the suffix for all Change Tables. The default value is __ct. The Change Table names are the name of the target table with the suffix appended. So for example, using the default value, the name of the Change Table will be HR__ct.
• Header column prefix: Specify a string to use as the prefix for all of the Change Table header columns. The default value is header__. For example, when using the default value, the header column stream_position will be called header__stream_position.

For more information on Change Tables, see Using Change Tables.

If change table exists when full load starts: Select one of the following to determine how to load the Change Tables when Full Load replication starts:

• Drop and create change table: The table is dropped and a new table is created in its place.

• Delete old changes and store new changes in existing change table: Data is truncated and added without affecting the table metadata.

  Information noteNot supported when Microsoft Fabric is the target platform.
• Keep old changes and store new changes in existing change table: Data and metadata of the existing Change table are not affected.

Table header columns

The Change Table header columns provide information about Change Processing operations such as the type of operation (e.g. INSERT), the commit time, and so on. If you do not need all of this information, you can configure the moving task to create the Change Tables with selected header columns (or none at all), thereby reducing their footprint in the target database..

For a description of the header columns, see Change Tables.

Error handling

Basic

Apply conflicts

Duplicate key when applying INSERT: Select what action to take when there is a conflict with an INSERT operation.

• Ignore: The task continues and the error is ignored.



• UPDATE the existing target record: The target record with the same primary key as the INSERTED source record is updated.

• Log record to the exceptions table (default): The task continues and the error is written to the exceptions table.

• Suspend table: The task continues but data from the table with the error record is moved into an error state and its data is not replicated.

• Stop task: The task is stopped and manual intervention is required.

No record found for applying an UPDATE: Select what action to take when there is a conflict with an UPDATE operation.

• Ignore: The task continues and the error is ignored.

• INSERT the missing target record: The missing target record will be inserted into the target table. When the source endpoint is Oracle, selecting this option requires supplemental logging to be enabled for all the source table columns.

• Log record to the exceptions table (default): The task continues and the error is written to the exceptions table.

• Suspend table: The task continues but data from the table with the error record is moved into an error state and its data is not replicated.

• Stop task: The task is stopped and manual intervention is required.

Advanced

Data errors

For data truncation errors: Select what you want to happen when a truncation occurs in one or more specific records. You can select one of the following from the list:

• Ignore: The task continues and the error is ignored.
• Log record to the exceptions table (default): The task continues and the error is written to the exceptions table.
• Suspend table: The task continues, but data from the table with the error record is moved into an error state and its data is not replicated
• Stop task: The task is stopped and manual intervention is required.

For other data errors: Select what you want to happen when an error occurs in one or more specific records. You can select one of the following from the list:

• Ignore: The task continues and the error is ignored.
• Log record to the exceptions table (default): The task continues and the error is written to the exceptions table.
• Suspend table: The task continues, but data from the table with the error record is moved into an error state and its data is not replicated
• Stop task: The task is stopped and manual intervention is required.

Escalate error handling when other data errors reach (per table): Select this check box to escalate error handling when the number of non-truncation data errors (per table) reaches the specified amount. Valid values are 1-10,000.

Escalation action: Choose what should happen when error handling is escalated. Note that the available actions are dependent on the action selected from the For other data errors drop-down list described above.

• Suspend table (default): The task continues, but data from the table with the error record is moved into an error state and its data is not moved.

  Information note

  The behavior differs according to the Change Processing Mode:

  • In Transactional apply mode, the last changes will not be moved.

  • In Batch optimized apply mode, a situation is possible where data will not be moved at all or only partially moved.

• Stop task: The task is stopped and manual intervention is required.
• Log record to the exceptions table: The task continues and the record is written to the exceptions table.

Table errors

Number of retries before returning a table error

This option allows you to control when the table error handling policy will be triggered. By default, after a table error is encountered, the table will be suspended or the task will be stopped (according to the selected action) after three retries. Sometimes, a table error will occur due to planned maintenance of the SaaS application. In these cases, the default number of retries might not be enough for the maintenance to be completed before the table error handling policy is triggered. This also depends on the task's scheduling interval as a retry will be performed each time the task runs. So, for example, if you schedule a task to run every hour and the SaaS application is taken offline for maintenance just as the task starts to run, the default of three retries will allow the SaaS application to be offline for up to three hours without the table error handling policy being triggered. A longer maintenance window would require you to increase the number of retries (or change the scheduling) to prevent the table error handling policy being triggered.

To sum up, if you aware that your SaaS application undergoes periodic maintenance, best practice is to increase the number of retries according to the scheduling so that the maintenance can be completed without table error handling policy being triggered.

When encountering a table error: Select one of the following from the drop-down list:

• Suspend table (default): The task continues but data from the table with the error record is moved into an error state and its data is not replicated
• Stop task: The task is stopped and manual intervention is required.

Escalate error handling when table errors reach (per table): Select this check box to escalate error handling when the number of table errors (per table) reaches the specified amount. Valid values are 1-10,000.

Escalation action: The escalation policy for table errors is set to Stop task and cannot be changed.

Apply conflicts

No record found for applying a DELETE: Select what action is taken when there is a conflict with a DELETE operation.

• Ignore: The task continues and the error is ignored.
• Log record to the exceptions table: The task continues and the record is written to the exceptions table.
• Suspend table: The task continues but data from the table with the error record is moved into an error state and its data is not replicated.
• Stop task: The task is stopped and manual intervention is required.

Escalate error handling when apply conflicts reach (per table): Select this check box to escalate error handling when the number of apply conflicts (per table) reaches the specified amount. Valid values are 1-10,000.

Escalation action: Choose what should happen when error handling is escalated:

• Log record to the exceptions table (default): The task continues and the error is written to the exceptions table.

• Suspend table: The task continues, but data from the table with the error record is moved into an error state and its data is not replicated.

  Information note

  The behavior differs according to the Change Processing Mode:

  • In Transactional apply mode, the last changes will not be replicated

  • In Batch optimized apply mode, a situation is possible where there will be no replication of data or data replication will be partial.

• Stop task: The task is stopped and manual intervention is required.

Environmental errors

• Maximum retry count: Select this option and then specify the maximum number of attempts to retry a task when a recoverable environmental error occurs. After the task has been retried the specified number of times, the task is stopped and manual intervention is required.

  To never retry a task, clear the check box or specify "0".

  To retry a task an infinite number of times, specify "-1"

  • Interval between retry attempts (seconds): Use the counter to select or type the number of seconds that the system waits between attempts to retry a task.

    Valid values are 0-2,000.

• Increase retry interval for long outages: Select this check box to increase the retry interval for long outages. When this option is enabled, the interval between each retry attempt is doubled, until the Maximum retry interval is reached (and continues retrying according to the specified maximum interval).
  • Maximum retry interval (seconds): Use the counter to select or type the number of seconds to wait between attempts to retry a task when the Increase retry interval for long outages option is enabled. Valid values are 0-2,000.

Change processing tuning

Transaction offload tuning

• Offload transaction in progress to disk if:

  The replication task usually keeps transaction data in memory until it is fully committed to the source and/or target. However, transactions that are larger than the allocated memory or that are not committed within the specified time limit will be offloaded to disk.

  • Transaction memory size exceeds (MB): The maximum size that all transactions can occupy in memory before being offloaded to disk. The default value is 1024.
  • Transaction duration exceeds (seconds): The maximum time that each transaction can stay in memory before being offloaded to disk. The duration is calculated from the time that the replication task started capturing the transaction. The default value is 60.

Batch tuning

The settings in this tab are determined by the Apply changes mode.

Setting that are only available when the "Apply mode" is "Batch optimized"

• Apply batched changes in intervals:

• Larger than: The minimum amount of time to wait between each application of batch changes. The default value is 1.

  Increasing the Longer than value decreases the frequency with which changes are applied to the target while increasing the size of the batches. This can improve performance when applying changes to target databases that are optimized for processing large batches.

• Less than: The maximum amount of time to wait between each application of batch changes (before declaring a timeout). In other words, the maximum acceptable latency. The default value is 30. This value determines the maximum amount of time to wait before applying the changes, after the Longer than value has been reached.

• Force apply a batch when processing memory exceeds (MB): The maximum amount of memory to use for pre-processing in Batch optimized apply mode. The default value is 500.

  For maximum batch size, set this value to the highest amount of memory you can allocate to the replication task. This can improve performance when applying changes to target databases that are optimized for processing large batches.

Setting that are only available when the "Apply mode" is "Transactional"

The following settings are only applicable when working in "Transactional" apply mode. Note that "Transactional" is the only available apply mode (and therefore not selectable) when replicating to Snowflake, and the Loading method is Snowpipe Streaming.

• Minimum number of changes per transaction: The minimum number of changes to include in each transaction. The default value is 1000.

  Information note

  The changes will be applied to the target either when the number of changes is equal to or greater than the Minimum number of changes per transaction value OR when the Maximum time to batch transactions before applying (seconds) value described below is reached - whichever occurs first. Because the frequency of changes applied to the target is controlled by these two parameters, changes to the source records may not immediately be reflected in the target records.

• Maximum time to batch transactions before applying (seconds): The maximum time to collect transactions in batches before declaring a timeout. The default value is 1.

Interval

Settings when using SAP ODP and SaaS application (Lite) connectors

• Read changes every (Minutes)

  The interval between reading changes from the source in minutes. The valid range is 1 to 1440.

  Information note

  This option is only available when the data task is defined with:

  • Data Movement gateway
  • Any of the following sources:
    • SaaS application via Lite connectors only
    • SAP ODP
  • The Apply changes or Store changes update method

Settings when using the SAP OData connector

Check for changes

• According to the delta extraction interval: When this option is selected, the data task checks for changes according to the Delta extraction interval.

  Information noteThe interval will start after each "round". A round can be defined as the time it takes for the data task to read the changes from the source tables, and send them to the target (as a single transaction). The length of a round varies according to the number of tables and changes. So if you specify an interval of 10 minutes and a round takes 4 minutes, then the actual time between checking for changes will be 14 minutes.

  • Delta extraction interval: The frequency with which deltas will be extracted from your system. The default is every 60 seconds.

• As scheduled: When this option is selected, the data task will extract the delta once and then stop. It will then continue to run as scheduled.

  Information noteThis option is only relevant if the interval between the CDC cycles is 24 hours or more.

  For information on scheduling:

  • "Replicate data tasks" in a replication project, see Scheduling tasks

Miscellaneous tuning

Statements cache size (number of statements)

The maximum number of prepared statements to store on the server for later execution (when applying changes to the target). The default is 50. The maximum is 200.

Store task recovery data in target database

Select this option to store task-specific recovery information in the target database. When this option is selected, The replication task creates a table named attrep_txn_state in the target database. This table contains transaction data that can be used to recover a task in the event that the files in the Data Movement gateway Data folder are corrupted or if the storage device containing the Data folder has failed.

Apply changes using SQL MERGE

When this option is not selected, the replication task will execute separate bulk INSERT, UPDATE and DELETE statements for each of the different change types in the Net Changes table.

While this method is highly efficient, enabling the Apply changes using SQL MERGE option is even more efficient when working with endpoints that support this option.

This is due to the following reasons:

• It reduces the number of SQL statements run per table from three to one. Most UPDATE operations in large, immutable, file-based cloud databases (such as Google Cloud BigQuery), involve rewriting of affected files. With such operations, the reduction of per-table SQL statements from three to one is very significant.
• The target database only needs to scan the Net Changes table once, significantly reducing I/O.

Optimize inserts

When Apply changes using SQL MERGE is selected together with the Optimize inserts option and the changes consist of INSERTs only, the replication task will perform INSERTs instead of using SQL MERGE. Note that while this will usually improve performance and thereby reduce costs, it might also result in duplicate records in the target database.

Transactional apply

The following settings are only available when working in transactional apply mode. When replicating to databases, the Apply mode can be set to either Batch optimized or Transactional. However, when replicating to Snowflake target and the Loading method is set to Snowpipe streaming, the apply mode is always transactional and therefore cannot be set.

• Minimum number of changes per transaction: The minimum number of changes to include in each transaction. The default value is 1000.

  Information noteThe replication task applies the changes to the target either when the number of changes is equal to or greater than the Minimum number of changes per transaction value OR when the batch timeout value is reached (see below) - whichever occurs first. Because the frequency of changes applied to the target is controlled by these two parameters, changes to the source records may not immediately be reflected in the target records.
• Maximum time to batch transactions before applying (seconds): The maximum time to collect transactions in batches before declaring a timeout. The default value is 1.

Schema evolution

Select how to handle the following types of DDL changes in the schema. When you have changed schema evolution settings, you must prepare the task again. The table below describes which actions are available for the supported DDL changes.

Character substitution

You can substitute or delete source characters in the target database and/or you can substitute or delete source characters that are not supported by a selected character set.

Substituting or deleting source characters

Use the Substitute or delete source characters table to define replacements for specific source characters. This may be useful, for example, when the Unicode representation of a character is different on the source and target platforms. For example, on Linux, the minus character in the Shift_JIS character set is represented as U+2212, but on Windows it is represented as U+FF0D.

Substituting or deleting source characters unsupported by the selected character set

Use the Unsupported source characters by character set table to define a single replacement character for all characters not supported by the selected character set.

More options

These options are not exposed in the UI as they are only relevant to specific versions or environments. Consequently, do not set these options unless explicitly instructed to do so by Qlik Support or product documentation.

To set an option, simply copy the option into the Add feature name field and click Add. Then set the value or enable the option according to the instructions you received.

Loading dataset segments in parallel

During full load, you can accelerate the loading of large datasets by splitting the dataset into segments, which will be loaded in parallel. Tables can be split by data ranges, all partitions, all subpartitions, or specific partitions.

For more information, see Replicating dataset segments in parallel.

Scheduling tasks

In the following use cases, you must define a scheduling interval to update the target with changes made to the source:

• Accessing a data source without Data Movement gateway
• Using a SaaS application Preview connector. Preview connectors are indicated by a button, both in the Create connection dialog and in the online help.
• When capturing changes from a SAP OData source using the As scheduled option.

The schedule determines how often the target datasets will be updated with changes to the source datasets. Whereas the schedule determines the update frequency, the dataset type determines the update method. If the source datasets support CDC (Change data capture), only the changes to the source data will be replicated and applied to the corresponding target tables. If the source datasets do not support CDC (for example, Views), changes will be applied by reloading of all the source data to the corresponding target tables. If some of the source datasets support CDC and some do not, two separate sub-tasks will be created (assuming the Apply changes or Store changes replication options are selected): one for reloading the datasets that do not support CDC, and the other for capturing the changes to datasets that do support CDC. In this case, to ensure data consistency, it is strongly recommended not to maintain the same scheduling interval for both tasks (if you decide to change the update frequency in the future).

For information about minimum scheduling intervals according to data source type and subscription tier, see Minimum allowed scheduling intervals.

To change the scheduling:

1. Open your project and then do one of the following:

   • In tasks view, click on a replication task and select Scheduling.
   • In pipeline view, click on a replication task and select Scheduling.
   • Open the replication task and click the Scheduling toolbar button.
2. Change the scheduling settings as needed and then click OK.

Executing a missed run for a task based on Data Movement gateway

Sometimes a network issue might result in the connection to Data Movement gateway being lost. If the connection to Data Movement gateway is not restored before the next scheduled run, the data task will not be able to run as scheduled. In such cases, you can choose whether or not to execute a run immediately after the connection is restored.

The default settings for all Data Movement gateways are defined in the Administration activity center. You can override these settings for individual tasks as described below.

To do this

1. Open your project and then do one of the following:

   • In tasks view, click on the data task and select Scheduling.

   • In pipeline view, click on the data task and select Scheduling.

   • Open the data task and click the Scheduling toolbar button.

   The Scheduling - <task> dialog opens.

2. Toggle on Use custom settings for this task.

3. At the bottom of the dialog, choose one of the following Run missed scheduled tasks options.

   • As soon as possible and then as scheduled if it's important to run a task before the next scheduled instance

   • As scheduled to run the task at the next scheduled instance

4. Save your settings.

See also: Executing a task run after a missed schedule.
